Production Bot Switch 4
Portable Live Broadcast Studio - Up to 4 Live Input/Output
Get the tools you need from Videolink!



Production Bot Switch 4

 Production Bot Switch 4

Production Bot Switch 4

Technical Specifications

System Intel Quad Core processor, NVIDIA GeForce GTX 1060 graphics, 32GB Memory, Dual Gigabit LAN, and Thunderbolt 3. Windows 10, vMix, vMix Social and vMix Title Designer preinstalled
Storage  500GB Internal SSD Storage.1TB additional storage in removable hot-swap bay. 4 hot-swap, tray-less drive bays for potentially unlimited plug and play storage
Video Inputs  Up to 4 simultaneous live HD-SDI video sources w/embedded audio in any combination of HD and SD format
Audio Inputs  16-channel SDI embedded, compatible with USB devices
Media 2x Balanced line-level XLR/TRS ¼” analog audio inputs 16-channel SDI embedded audio. Compatible with USB audio devices
Memory 64 GB DDR4 2133Mhz RAM
Transitions  Cut, Fade, Zoom, Wipe, Slide, Fly, CrossZoom, FlyRotate, Cube, CubeZoom, VerticalWipe, VirtualSlide, Merge and two custom Stinger channels.
Mix/Effects Each input includes 5 "Multi View" overlay channels to create complex Mix/Effects. Add logo bugs, lower thirds, titles, text in combinations to create compelling productions.
Downstream
Keyers
4 DSKs / overlays with individual transitions, alpha channel and custom scaling/positioning.
Image Adjustment Color Correct, Deinterlace, Sharpen, Zoom, Rotate, Pan and Crop any input in real time. All effects are processed in 4:4:4 32bit color space for optimal video quality.
Audio Mixer Independent control and monitoring of all audio sources with Mute, Solo, Follow (Auto Mixing), Delay, EQ, Compressor and Gain.
Virtual Sets 6 free virtual sets from Virtualsetworks.com. 5 built-in sets with full motion camera presets and high quality GPU-based chroma key. Easily build your own virtual set using standard tools.
